Junction Details

1.1 SHADOW GAP

3-10mm depending on rib
size. Paint the gap black before application if needed.

1.2 METAL PROFILE

Can match other framing details within your concept.

1.3 TIMBER DETAIL

Can reflect other timber finishes in the scheme to create a panel break or fixing location.

1.4 ALUMINIUM 'C' SECTION

Creates a shadow gap with clean termination for the ribbed material. Can be finished in any colour.

Joins that run perpendicular to the rib direction can be expressed in various ways.

Joins that run parallel to the rib direction are invisible with careful cutting in the trough of adjacent ribs.

Acoustic Build-up

Applied direct to walls the acoustic performance of the ribbed materials is Class C or D.

For greater absorption additional backing is required to absorb bass energy.

3.1 ACOUSTIC PERFORMANCE

Can reach up to Class A with the addition of 30mm acoustic backing (Cellofoam 615) behind the ribbed top layer. Any of the junction details can be amended for the increased thickness.

Cellofoam 615

Timber detail

Wall

Corner Details

2.1 INTERNAL CORNERS

Are improved by putting a relief cut in the backing material.

2.2 EXTERNAL CORNERS

Area also improved by the addition of a relief cut in the backing material.

2.3 CORNER PROFILE

Can wrapped in matching leather to create a more robust corner junction.

4.4 END STOP

Can be produced to match the rib size and material choice. These can also be mitred to create framing around doors and other penetrations.

Curves, corners and ends stops all work well with various approaches.

Corners and ends can be detailed as followed.

Detailing

This page describes suitable junction treatments when designing with buxkin.

Designing details with BUXKIN products
